HONLED is a prominent injection molding machine supplier, recognized for its horizontal molding machines and auto injection machines. These auto injection machine are designed for precision and automation, enhancing the efficiency of plastic part production.
HONLED's horizontal molding machine are equipped with advanced technologies, ensuring reliable operation and minimal downtime. They cater to a variety of applications, from the production of small components to large plastic parts, offering cost-effective solutions for the plastic manufacturing industry. With a strong focus on innovation and quality, HONLED continues to deliver state-of-the-art auto injection machine that meet the highest standards of performance.
Product Description
The HYJ-1700 Horizontal Injection Molding Machine is an advanced piece of equipment specifically designed for precision and efficiency in the manufacturing process. Its horizontal design provides stability and consistency in producing high-quality plastic products, while its advanced injection molding technology allows for precise control over the molding process, resulting in uniformity and accuracy in the final product. This horizontal molding machine is suitable for a wide range of applications, from automotive parts to consumer goods, making it a versatile and valuable asset for any production facility.
Item | HYJ-1700 | |||
INJECTION UNIT | A | B | C | |
Screw diameter | mm | 42 | 45 | 48 |
Screw L/D ratio | L/D | 22.4 | 20.2 | 18.9 |
Shot volume | cm³ | 301 | 346 | 391 |
Shot weight(ps) | g | 284 | 326 | 371 |
Injection pressure | Mpa | 232 | 190 | 165 |
Injection rate(ps) | g/s | 114 | 139 | 159 |
Screw stroke | mm | 210 | ||
Screw speed(stepless) | r/min | 0~230 | ||
CLAMPING UNIT | ||||
Clamping force | KN | 1580 | ||
Opening stroke | mm | 400 | ||
Opening stroke | mm×mm | 470×420 | ||
Opening stroke | mm | 470 | ||
Opening stroke | mm | 180 | ||
Opening stroke | mm | 130 | ||
OTHERS | ||||
Hydraulic system pressure | KW | 22 | ||
Certification
FAQ
1.Q:What is a horizontal injection molding machine?
A:The Horizontal Injection Molding Machine is an injection molding equipment in which the injection device and the clamping device are horizontally arranged, and the mold opens and closes in the horizontal direction. Its body is low and the center of gravity is stable. The products can automatically fall off by gravity, making it suitable for automated mass production. It is widely used in the fields of large parts such as automotive components and daily necessities. Compared with vertical models, it is more convenient to maintain and has higher long-term cost-effectiveness.
2.Q:What is the difference between vertical and horizontal injection molding machine?
A:The main difference between vertical and horizontal injection molding machine is the structure layout and application scenario: the vertical injection molding machine is an injection device and a clamping device arranged vertically. It has a small footprint, whichis suitable for the production of precision small parts or insert-type products. The horizontal injection molding machine is horizontal laid out, fully automated, convenient maintenance, and is suitable for the large-scale production of large parts. The vertical injection molding machine has a better resistance to seismic performance, and the horizontal injection molding machine has a higher long-term cost performance.
3.Q:How much does an injection mold machine cost?
A:The price of an injection molding machine specifically depends on the equipment specifications (clamping force, injection volume), the degree of automation, and the differences in brand technology. The cost of small standard models is relatively low, while the prices of large high-precision or multi-color models increase significantly. It is recommended to contact HONLED for an accurate quotation according to your needs.
Company Profile
As a top injection molding machine supplier,HONLED Plastics Machinery Co., Ltd has been committed in producing high quality thermoset molding machine producer since its foundation at 1998. Our company occupies 8000M with the capacity of 1000 sets per year of injection machine, the clamping force from 30T to 1000T.
And our company have passed IS09002 certification and all of our machine have got CE certification.
Now we have served severalthousand domestic customers and exported to more than 30 countries.
